Grade	Tensile strength.min		Yield strength,0.2% offset				Elongation (%)
Grade	ksi	ksi	ksi(min)	MPa(min)	ksi(max)	MPa(max)	Elongation (%)
Gr1	35	240	20	138	45	310	24
Gr2	50	345	40	275	65	450	20
Gr3	65	450	55	380	80	550	18
Gr4	80	550	70	483	95	655	15
Gr5	130	895	120	828	/	/	10
Gr7	50	345	40	275	65	450	20
Gr9	90	620	70	483	/	/	1

Titanium rod and TC4 titanium alloy rod have excellent properties such as low density, high specific strength, corrosion resistance, small coefficient of linear expansion and good biocompatibility. They are indispensable structural materials in aviation, aerospace, ocean transportation, chemical industry, metallurgy, medical and health care industries. The titanium bar and titanium alloy bar used in industry at first are all deep-processing parts. With the increase of its consumption and the expansion of its application scope, the deformation reflects the disadvantages of large machining amount, low material utilization rate and high production cost, so the casting technology is developed. Titanium casting is an economical and easy forming process. Titanium and titanium alloy have high chemical activity in molten state. It is very difficult to melt and cast because of chemical reaction with common refractory materials. It is necessary to have special molding materials, molding process and special melting and casting equipment

Application of titanium hex rod

Aerospace Industry

Titanium rods are also used in aircraft frame structures. Titanium rods are also used for moving parts of aircraft engines and propellers. The aerospace industry is the largest market for titanium rods and products.

Portable computer

Manufacturers use titanium rods because of its industrialized, modern and shiny appearance. Apple uses titanium strips in the body of its powerbook laptop. Notebook computer manufacturers use titanium in different processes of notebook computer manufacturing. The notebook computer industry is the largest consumer of fine titanium rods.

Armor

Titanium rods are very lightweight and high strength, which is why armor manufacturers use titanium rods in the manufacturing process to make armor lightweight and easy to wear. Armor manufacturers use titanium rods in different types of applications to reduce weight and make products more durable.
