Products Description
Test data shows that compared to carbon paper and powder titanium plate, titanium felt has the lowest ohmic resistance, resulting in the lowest overpotential, which reduces energy consumption and improves electrolysis performance.
Moreover, the voltage is lower than that of carbon paper and powder titanium plate, indicating that titanium felt has better electrolysis performance.The high porosity and large pore size of titanium felt are conducive to gas emission and liquid circulation.
PEM electrolytic titanium fiber felt
Electrolyzer core components
Smooth surface And high porosity
The pores are in a three-dimensional structure, and the resistance of gas and liquid passing through is small
Good uniformity and strong bonding
Stable electrolytic performance, low resistance and low energy consumption
Product Production
Titanium fiber felt is made of titanium wire through a special process into micron-level fibers. The titanium fibers are laid and sintered to make porous materials. Its unique three-dimensional grid fiber and fully interconnected porosity structure give it a series of special functions.
Titanium Felt Test
Titanium fiber felt performance test
Polarization curve, impedance test, current density, stability test
product key technologies
Titanium fiber felt
Can provide micrometer sized titanium fiber felt
Titanium sintered fiber felt
The surface can be treated with corrosion resistance and coated with precious metal coatings
Titanium fiber felt technical parameter table
Titanium fiber felt
Technical parameter table
Ultra-thin titanium fiber felt(0.1-0.25mm)
In the proton exchange membrane (PEM) electrolyzer, the 0.25mm thick titanium fiber felt plays a key role as the gas diffusion layer (GDL) on the anode side.
Titanium fiber felt for general use(0.4 and 0.6mm)
0.4mm gauge: As an electrode substrate for redox flow batteries (such as vanadium batteries), its porosity (typically 50–60%) and thickness optimize electrolyte distribution, reduce concentration polarization, and improve energy storage efficiency.
0.6mm gauge: For high-power flow battery systems, it enhances mechanical support and prevents electrode deformation while maintaining high conductivity and chemical stability.
Titanium felt (thickened version)
Core Advantages: High mechanical strength + high-temperature creep resistance
Typical Applications: Industrial high-pressure filtration, SOFC support layers, and medical substrates
Titanium fiber felt inventory
We have standard sizes in stock and no minimum order quantity is required.
For non-standard sizes, we do have a minimum order quantity of 1 square meter.
Products Description
PEM pure water electrolysis hydrogen production industry：
Titanium fiber felt, when used as the anode electrode in PEM (Pure Electrometic Molecular Electrolysis) hydrogen production cells, demonstrates its superior oxidation resistance, water permeability, and heat dissipation. Especially when used as the anode catalytic electrode, it enables high current density and long-life electrolyzers.
It is a preferred material for improving hydrogen purity and enhancing electrolyzer stability and lifespan, particularly in hydrogen production.
PEMFC fuel cell industry：
Titanium fiber felt is also widely used in the fuel cell industry, whether as a gas diffusion layer or a water diffusion layer. Currently, Toyota's latest generation of most advanced hydrogen fuel cell vehicles uses titanium fiber felt instead of carbon paper.
Precious metal coating
The main reasons for coating titanium fiber felt with precious metal coating in PEM electrolyzers include the following:
-
(1) Conductivity optimization
-
The coating needs to provide a low-resistance electron transport path, with a target resistivity of less than 10⁻⁴ Ω·cm (ohm·cm). The interface contact resistance can be reduced by introducing highly conductive materials (such as amorphous carbon, TiC (titanium carbide)) and gradient structure design.
-
-
(2) Corrosion resistance improvement
-
In a strong acidic (pH = 1~3) and high potential (1.8~2.0 V) environment, the coating needs to inhibit the corrosion of Cl⁻ (chloride ions) and H⁺ (hydrogen ions) to avoid substrate dissolution and passivation film rupture.
-
-
(3) Catalytic activity enhancement
-
The coating needs to reduce the OER (oxygen evolution reaction) reaction barrier and improve hydrogen production efficiency. Precious metal oxides (such as IrO₂, iridium oxide) and transition metal compounds (such as Nb₂O₅, niobium pentoxide) are selected as catalytic active components.
