hexagon stock head cap titanium screw

What is the hexangon stock head cap titanium screw?

Titanium hexagon socket screw, as the name suggests, is a kind of hole type screw produced by titanium material. Its mechanical properties are the same as cylindrical head hexagon socket screws. The production and processing of titanium hexagon socket screws are first cut and punched, and then the pitch is completed. Titanium hexagon socket screws have high hardness, expensive materials, and difficult to process. The company has many years of experience in titanium screw product processing. The titanium hexagon socket screws produced meet national and international fastener standards and have a beautiful appearance.

hexagon socket head cap titanium screw

d	b	t min	s	k max	dk
M2	16	1	1.5	2	3.8
M3	18	1.3	2.5	3	5.5
M4	20	2	3	4	7
M5	22	2.5	4	5	8.5
M6	24	3	5	6	10
M8	28	4	6	8	13
M10	32	5	8	10	16
M12	36	6	10	12	18
M14	40	7	12	14	21
M16	44	8	14	16	24
M18	48	9	14	18	27
M20	52	10	17	20	30
M24	60	12	19	24	36
M27	66	13.5	19	27	40
M30	75	15.5	22	30	45
M36	84	19	27	36	54

din912 titanium screw

Why are hexagon socket screws so popular?

Why are hexagon socket screws used in many industrial equipment? What's so good about them? The screw heads of hexagon socket screws are round on the outside and a recessed hexagon in the middle. The advantage of this structure is actually obvious.

1. The load bearing is large. There are six stress surfaces of the hexagon socket screw. Compared with the slotted screw and the Phillips screw with only two surfaces, it must be able to handle it.

2. It can be countersunk, that is, the entire nut sinks to the inner surface of the workpiece, which can keep the surface of the workpiece smooth and beautiful.

3. Convenient installation. Compared with the outer hexagonal screws, the inner hexagon is suitable for many assembly occasions, such as narrow ones, so it is very convenient for assembly and maintenance, and it is also convenient for debugging.

4. It is not easy to disassemble. The tools we usually use are adjustable wrenches, screwdrivers and open wrenches, and special wrenches are used to disassemble the hexagonal screws. Therefore, it is not easy for ordinary people to disassemble, which is also an advantage.

hexagon socket screws is the higher the performance level, the greater the strength. When choosing screws, we must strictly follow the requirements of use. Suitable performance grade screws, different grades, naturally the price is also different.

titanium hexagon socket head cap screw
