Products Description
The platinum-coated titanium anode sheet can be used in various media, and has strong activation and high efficiency in electrochemical reactions. It has a good bonding force with titanium plates
Product display
| Material | Grade 1 Titanitum as substrate |
| Technology | platinum as coating |
| Dimension | Different dimension and shape is available |
| Shape | or according to client's drawing |
| Packaging and transportation | Stock size shipped within 3 days Custom sizes shipped in 15 days |
| Sample service | Support sample service |
| Packing method | Packed in wooden cases or cartons |
Is using titanium anodes environmentally friendly?
Corrosion resistance: Titanium anodes are corrosion resistant and can remain stable under various harsh environmental conditions
Long life: Titanium anodes can be used for a long time, which can reduce the frequency of replacement, so that the cost is reduced.
Low energy consumption: Titanium anodes have low energy consumption characteristics, which can produce results at low current density. Reduced energy consumption and loss.
Operation controllability: Titanium anode operation control is relatively simple, can achieve automatic control.
Correct use of platinum-coated titanium anodes sheet
1. Before using the platinum-plated titanium anode, it is necessary to exclude the presence of "fluorine" ions in the plating solution (must be detected), and the components that have no corrosive effect on the platinum-titanium electrode can be used. Otherwise, the platinum-titanium electrode substrate will be seriously corroded and shorten the service life.
2, reasonable selection of the best process, anode current density is best to choose 50A/dm2, tank voltage below 10V, otherwise affect the service life, serious will cause the anode melting holes, platinum layer fall off.
Try to choose the anodizing reaction without solid oxide generation process, to avoid oxide thickening passivation affect the Yang to conduct electricity.
3. In principle, the surface area of the plated cathode should be less than the effective anode area (that is, the anode area under the liquid level), and the anode area should not be used when it is less than the cathode area, otherwise the anode is easy to breakdown. Cannot be used normally.
4, when the plating tank impedance increases, the tank pressure will also increase, when the tank pressure exceeds 10V, should not continue to increase the current, but should adjust the current properly, such as: high current 10% while the plating time is extended by 10%(as long as the hardness is not affected).
5, After the platinum-coated titanium anode plate is used, clean it with deionized water, then remove it from the plating tank, and then store it in a pure tank
6, Rust in tap water stored for a long time will adhere to the electrode surface, which will affect subsequent use
The process of titanium anode electroplating electrolysis
Electroplating is the coating of other rust-resistant metal substances on the product through electrolyte action; The anodizing is only the pre-oxidation of the surface of the product itself, but both can play a role in rust prevention; The appearance of electroplating is the color of metal coating, and zinc anodizing can achieve a variety of colors such as gold and red. Electroplating is a kind of cathode treatment, that is, the part as a cathode, adsorbing the metal ions of the anode, covering the surface, forming a coating, increasing hardness, anti-corrosion, increasing wear resistance and so on. Anodizing is the part as an anode, making itself oxidized, forming an oxide layer, and playing a role in preventing corrosion. In addition, after oxidation, according to different requirements and metals, different colors can be made, and it can also be hardened and wear-resistant.
Electroplating is through direct current action on the electroplating solution to cause electrochemical changes on the electrode. On the cathode, the material gets electrons and is reduced to form a coating layer on the cathode: such as chromium, nickel, gold, copper, etc. The material on the anode loses electrons and is oxidized, and the material on the anode enters the plating solution, such as nickel, copper, and so on. Aoxin anti-corrosion materials that anodizing is in the anodizing liquid with high pressure direct current to oxidize the anode surface of oxygen and other oxidizing substances to oxidize the anode itself, resulting in a dense oxide surface, resulting in corrosion resistance, with a certain hardness of the surface, such as zinc anodizing.
Transport and logistics
Usually our factory uses wooden cases for packing
Generally use the international four express delivery, support sea and air transport
